Catheter Hole Punching & Drilling

Our cutting, drilling & punching solutions are designed with the tightest tolerances and most difficult material in mind, including flexible, soft, brittle, braided and non-braided materials such as silicone, PEEK, nylon, polytetrafluoroethylene (PTFE) and Pebax®, stainless steel, and nitinol wire.

Cathtip 400 Series

The 400 Series is a precision hole forming machine that delivers results to the highest industry hole quality standards and is custom built to suit your application’s specifications.

Cathtip Flex-Drill

Flex-Drill by CATHTIP is the most flexible, cost-effective option for hole forming in catheter prototypes and early development applications.

Other DRILLING/PUNCHING Technology

Accu-Drill MD

The Accu-Drill MD10 Manual Hole Driller is capable of drilling and skiving precise holes in plastic, silicone and steel braided medical tubing.

Accu-Drill SD

The Accu-Drill SD Automated Hole Driller is a powerful, safe solution for catheter hole drilling and skiving patterns requiring one to four axes of control.
